Zolar Vega 30C RGBAW LED Light Panel

SKU: ZO V03202

Product Highlights

  • CRI: Ra ≥ 97 (R9 & R12 up to 97), TLCI ≥ 98;
  • Spectral Similarity Index SSI up to 90
  • Full RGBAW Color Gamut
  • CCT range: 2,000K ~ 20,000K
  • DMX, Art-Net 4 & sACN + powerCON
  • ZOLAR Stylist precision directional super light transmissible panel: control beam angle, light diffusion, no color shift;
  • Multi Light Sync - ZolarLink (wireless / cable), rapid auto sync grouping;
  • Built in Light Effect (synchronized) for different scene applications;
  • Bluetooth + Wi-Fi mixed control: Remote Controller, mobile app (iOS & Android).
$1,238.00 (inc GST)

Quantity

ZOLARTM professional LED lighting system is developed by Shenzhen ImagineVision Technology Limited, the same successful team that created Z CAM Cinema Cameras. ZOLARTM products are developed with profound color science knowledge, leading image processing algorithms, as well as camera lens and sensor calibration expertise. Delivering high fidelity color reproduction and excellent color rendition with performances very close to natural daylight.

Our in-house developed Self Adaptive Spectral Nonlinear Dynamic Illuminance Calibration System eliminates the inconsistent LED performance issues. In addition, our revolutionary solution allows a mixture of ZOLARTM light series to be used simultaneously without any visible color deviation (color matching mode will be added to other ZOLARTM series).

ZOLARTM Vega is a 5-color LED light panel series targeting professional video productions. Its wide CCT range, excellent soft light performance and high fidelity color reproduction has set a new benchmark for the industry. Designed with 5-color full spectrum LEDs and RGBAW algorithm to deliver continuous light spectrum across full CCT range with exceptionally high CRI & TLCI scores, particularly in R9, R12, R13 & R15. No compromise.

Spectral Similarity Index (SSI) is developed by The Academy of Motion Picture Arts and Sciences to evaluate the fidelity of color reproduction particularly for LED light, from a single chip CMOS digital camera point of view. It quantitatively compares the spectrum of the test light with that of a desired reference light source, expressing the similarity as a single number on a scale up to 100. High values indicate a high likelihood of high fidelity color reproduction by most cameras. SSI of ZOLARTM Vega is close to or exceeds 90, across full CCT range (2,000K~20,000K), a leading standard in the industry.

Higher score implies higher fidelity color reproduction, particularly the skin tone. This is exactly why these scores exist.

What's in the box?

  • 1 x ZOLAR Vega 30C Main Unit
  • 1 x Yoke Mount
  • 1 x Remote Controller
  • 1 x Power Supply Unit
  • 1 x ZOLAR Stylist W 32x32
  • 1 x Power Cable (AC & DC & Battery)
  • 1 x Remote Connector Cable
  • 1 x Quick User Guide
  • Model
  • Vega 30C
  • LED Type
  • 5-color, Full Spectrum
  • White Light
  • 2,000K to 20,000K continuously variable correlated color temperature
  • Colored Light
  • Full RGBAW Color Gamut with Hue and Saturation Control
  • Light Diffusion System
  • Reflective Membrane +ZOLAR Stylist
  • Color Rendition
  • CRI: Ra ≥ 97 (R9 & R12 up to 97), TLCI ≥ 98
  • Spectral Similarity Index
  • SSI up to 90
  • Light Aperture
  • 240mm x 240mm (9.45" x 9.45")
  • Dimming
  • 0 ~ 100 % continuous (Main Unit Controller 0.1% precision), different dimming curves, smooth dimming down to zero without color shift.

  • Color Temperature Tolerance
  • +/- 100 K (nominal)
  • Tilt Angle
  • ± 360°
  • Handling
  • Aluminium Yoke, Tilt Lock Clamping Lever, Pole Operation for pan & tilt
  • Mounting
  • 16 mm / 28 mm Combo Pin (Baby 5/8" / Junior 1-1/8" Combo Pin) / 28 mm Spigot (Junior Pin)
  • Multi Light Sync
  • ZolarLink™ - Multi Light Sync Protocol, up to 16 groups with 60 slave units maximum per group (wireless); up to 32 units maximum per group (cable).
  • Control
  • Main Unit Controller
  • Remote Controller
  • Remote Controller, cable length 5m (16.4 ft)
  • Wireless Control
  • WiFi, Bluetooth, ZOLAR Mobile App, Art-Net 4 & sACN protocol
  • Remove Device Management (RDM)
  • DMX Setup, Standard RDM commands

  • Ethernet
  • Ethernet connectivity, Art-Net 4 & sACN protocol
  • DMX
  • 5-Pin DMX In, 5-Pin DMX Out
  • Dc Input Power
  • 48V, 5.2A DC
  • Power Input
  • Male 3-Pin XLR - 15A (Pin 1: Negative / Pin 2: Positive)

  • Battery Input
  • Dual V-Mount, 12.8 ~ 16.8V (180Wh min.)
  • PSU
  • 110 ~ 240V, AC loop out, powerCON
  • Power Consumption
  • 250 W maximum
  • Cooling System
  • Low Noise Fan mode (Auto, High, Mid, Low)
  • Ambient Temperature Operation
  • -20ºC ~ +45° C (-4ºF ~ +113°F)

  • Estimated LED Lifetime
  • 50,000 hours (L70)
  • Estimated Color Shift Over Lifetime (CCT)
  • +/- 5%

  • Weight
  • Weight (Main Unit) 3.67 kg / 8.09 lb (Main Unit + ZOLAR Stylist W)

    Weight (Main Unit) 4.53 kg / 9.99 lb (Main Unit + ZOLAR Stylist W + Yoke)

    Weight (Full Package) 11.58 kg / 25.53 lb (Main Unit + ZOLAR Stylist W + Yoke + AC DC Power Adapter + Remote Controller + Packing Materials)

  • Dimensions
  • Measurements (HxWxL) 475 x 420 x 130 mm / 18.70 x 16.54 x 5.12 inch (Main Unit + Yoke)

    Measurements (HxWxL) 580 x 540 x 330 mm / 22.84 x 21.26 x 12.99 inch (Full Package)

  • Certifications
  • CE, FCC, SRRC
